JBS AUDIO WMX 200D VOCAL
Šifra: 10076
284,00 KM
243,00 KM (Bez PDV-a)
Iznos rate:
Prikazana cijena je za komad.
Garantujemo najnižu cijenu!
RECEIVER SPECIFICATIONS Channel Frequency: 170- 260Mhz Sensitivity: 95dBm (S/N:12dB) RF Image Rejaction-75dB Audio Dynamic Range:95dB T.H.D.<1% Frequency stability: 0.002% S/N Ratio: >70dB Neighboring Channel/ Interference: >70dB Frequency Response: 50Hz-15Khz 3dB Power Requitements: 13 15V DC nominal 150mA Dimensions: 17.5x13.5x4.3cm
RECEIVER SPECIFICATIONS
Channel Frequency: 170- 260Mhz
Sensitivity: 95dBm (S/N:12dB)
RF Image Rejaction-75dB
Audio Dynamic Range:95dB T.H.D.<1%
Frequency stability: 0.002%
S/N Ratio: >70dB
Neighboring Channel/ Interference: >70dB
Frequency Response: 50Hz-15Khz 3dB
Power Requitements: 13 15V DC nominal 150mA
Dimensions: 17.5x13.5x4.3cm
HANDHELD TRANSMITTER SPECIFICATIONS
Carrier Frequency:170-260Mhz
RF power Output: >13dBm
Modulation Degree: >30KHz
power Current: <110mA
Frequency Stability +- 0.002%
Harmonic at Higher Degree: <60dB
Modulation pattern: FM
Power Requitements: 3V (2x1.5V AA)
Dimensions: 25x5, 1x5, 1cm
