Neutrik NAC3MPXXB - Ugradni izlazni PowerCON
*Cijena sa popustom može da se ostvari ukoliko se plaća gotovinski, virmanom (preko računa) ili odmah debitnom i kreditnom karticom.
Garantujemo najnižu cijenu!
This connector is fully compliant to the device standard IEC 62368-1, due to its component certification according to IEC 60320-1.
Appliance outlet connector, 3/16" flat tab terminals, grey
The powerCON XX is a locking mains connector. It replaces appliance couplers wherever a very reliable solution in combination with a locking device is needed in order to guarantee a safe power connection.
The powerCON XX is a connector with breaking capacity (CBC), i.e. it can be connected or disconnected under load or live.
| Product | |
| Title | NAC3MPXXB |
| Gender | male |
| Electrical | |
| Contact resistance | ≤ 2 mΩ |
| Dielectric strength | 4 kVdc / 2.8 kVac |
| Insulation resistance | > 10 GΩ (initial) |
| Number of electrical contacts | 2 + PE |
| Rating Europe | EN 60320-1: 16 A 250 V AC |
| EN 61984: 20 A 250 V AC | |
| Rating USA | UL 60320-1:20 A 127 V AC |
| UL 1977: 20 A 250 V AC |
| Mechanical | |
| Lifetime | > 5000 mating cycles |
| Wiresize | 2,5 mm² |
| Wiresize | 12 AWG |
| Material | |
| Contact plating | Ag |
| Locking element | Stainless steel |
| Shell | Polyamide (PA 6.6) |
| Contacts | Copper Alloy |
| Environmental | |
| Flammability | UL 94 V-0 |
| Protection class | IP 20 |
| Temperature range | -30 °C to +80 °C |
